- 3840Hz Refresh Rate
- Snap on Back Cover
- Slim & Light weight
- Dual Module Sizes: 320x160mm and 320x180mm
- Support Automatic Adjustment of Brightness and Color Temperature
The Leyard LUS Series offers a lightweight yet high-strength module, designed for exceptional load-bearing capacity and long-term durability. Engineered with mechanical precision and high-strength materials, this module ensures superior performance and reliability. Its screwless structure enhances flatness and allows for easy serviceability of components, minimizing maintenance time and effort. The Leyard LUS Series is ideal for environments such as Command Centers, Multifunction Rooms, and Meeting Rooms, where precision, reliability, and efficiency are paramount. With its sleek design and high-performance capabilities, it guarantees clear, consistent, and visually stunning displays in any application.
Item
Pixel Pitch (mm)
Module Size (mm) (WxH)
White Balance Brightness (nits)
Color Temperature (K)
Peak Power Consumption (W/㎡)
Avg Power Consumption(W/㎡）
Refresh Rate (Hz)
Operation Temperature (℃)
Operation Humidity (RH)
LUS0100
1
320*160
≥500
3000~38000 Adjustable
≤440
≤148
≥3840
-10~40
10~80% no condensation
LUS0125
1.25
320*160
≥500
3000~38000 Adjustable
≤440
≤148
≥3840
-10~40
10~80% no condensation
LUS0153
1.538
320*160
≥500
3000~38000 Adjustable
≤352
≤118
≥3840
-10~40
10~80% no condensation
LUS0186
1.86
320*160
≥500
3000~38000 Adjustable
≤352
≤118
≥3840
-10~40
10~80% no condensation
LUS0200
2
320*160
≥500
3000~38000 Adjustable
≤352
≤118
≥3840
-10~40
10~80% no condensation
LUS0250
2.5
320*160
430~450/≥600
3000~38000 Adjustable
≤230/≤396
≤77/≤132
≥3840
-10~40
10~80% no condensation
LUS0300
3.076
320*160
500~550
3000~38000 Adjustable
≤308
≤103
≥3840
-10~40
10~80% no condensation
LUS0400
4
320*160
≥600
3000~38000 Adjustable
≤370
≤123
≥3840
-10~40
10~80% no condensation
